5Kohm Trimmer Pot, Top Adjust
5Kohm Trimmer Pot, Top Adjust
- Voltage and Current Control Circuits
- Used as volume control knobs in radios
- Tuning or controlling circuits
- Analog input control knobs
Safe shopping
Your data is always protected
Sale_coupon_15
2,50EGP
In stock
In stock
11
People watching this product now!
-
Pick up from the Store
Everyday from 9 AM to 7 PM
-
ARAMEX DELIVREY
2-3 Days
Total fees when checkout
-
Return within 14 days
Payment Methods:
Description
5Kohm Trimmer Pot, Top Adjust
A Trimpot is another type of potentiometer that comes in small package. It has three leads and can be easily mounted on breadboard or perf board for quick prototyping. The value of the pot can changed by varying the knob on top of it.
Specifications:
| Resistance (?) | 5K |
| Tolerance(%) | 30 |
| Operating Temperature Range (?C) | -10 to 70 |
| Mounting Type | Through Hole |
| Length (mm) | 7 |
| Width (mm) | 6.5 |
| Height (mm) | 5 |
| Weight (gm) | 0.1 (approx.) (each) |
| Shipment Weight | 0.005 kg |
| Shipment Dimensions | 2 ? 2 ? 2 cm |
Features:
- Type: Preset Potentiometer – Trimpot
- Available in standard or carbon film type
- Available in different resistance values like 500?, 1K, 2K, 5K, 10K, 20K, 50K, 100K, 200K,1M.
- Maximum operating Voltage: 50V DC
- Rotational Life: 20 cycles
Applications:
- Voltage and Current Control Circuits
- Used as volume control knobs in radios
- Tuning or controlling circuits
- Analog input control knobs
Package Includes:
- 1x Preset Potentiometer
Product Datasheet:
